Performance Characteristics

1) The product design concept, material selection, and manufacturing process are all entirely new. Therefore, it is not only small in size, light in weight, and aesthetically pleasing, but also meets all technical specifications of the JB3570-98 standard.

2) It uses high-quality cold-rolled DQ-151 oriented silicon steel sheets stacked into a multi-stage cylindrical frame core, and a high-voltage tower coil is directly and continuously wound with QZ-type wires on a specially made high-strength insulating cylinder.

3) It generally provides AC output. If DC output is required, an external high-voltage rectifier silicon stack can be installed at the high-voltage output end.

Technical indicators
